Springfield XD 5" Tactical Schematic

To access product listings, click on the part, part number or part name.

Springfield XD Tactical
  1. Barrel
  2. Disassembly Lever
  3. Ejector
  4. Ejector Pin
  5. Extractor
  6. Front Sight
  7. Grip Safety
  8. Grip Safety Pin
  9. Grip Safety Spring
  10. Guide Rod
  11. Loaded Chamber Indicator
  12. Loaded Chamber Indicator Pin
  13. Loaded Chamber Indicator Spring
  14. Locking Block
  15. Locking Block Pin, Trigger Pin
  16. Locking Block Pin Retainer, Trigger Pin Retainer
  17. Magazine
  18. Magazine Base
  19. Magazine Body
  20. Magazine Catch
  21. Magazine Catch Pin
  22. Magazine Catch Spring
  23. Magazine Follower
  24. Magazine Locking Plate
  25. Magazine Release Button
  26. Magazine Spring
  27. Rear Sight
  28. Receiver
  29. Recoil Spring
  30. Sear
  31. Sear Pin
  32. Sear Spring
  33. Slide
  34. Slide Stop Lever
  35. Slide Stop Lever Spring
  36. Striker
  37. Striker Dampening Spring
  38. Striker Locking Plate
  39. Striker Retainer Pin
  40. Safety
  41. Striker Safety Lever
  42. Striker Safety Retaining Pin
  43. Striker Safety Spring
  44. Striker Spring
  45. Striker Spring Guide
  46. Striker Status Indicator
  47. Trigger Bar
  48. Trigger Bar Spring
  49. Trigger with Safety
